    Description

    whisper-quiet compressor JUN-AIR 4-25 motor oil lubricated with pressure reducer JUNAIR”.
    from 2007

    The oil-lubricated JUN-AIR compressors are always the optimal solution,
    when a noiseless compressed air supply is required.
    At 45 dB(A), the volume is well below the sound level of a normal conversation.
    Silent, vibration-free operation and the compact design allow installation directly at the workplace.

    Technical data:
    max. Pressure 18 bar
    Suction capacity 50 l/min
    Effective delivery rate: 32 l/min at 8 bar
    Volume 45 dB(A)
    Duty cycle / pause 15 min. / 15 min.
    Compressor number 1
    Cylinder per compressor 1
    Pressure vessel volume 25 l
    Permissible ambient temperature +1°C to +40°C
    Supply voltage 230 V, 50 Hz
    Motor power 0.34 kW
    Current consumption 2.9 A
    Thermal protection Integrated
    Weight 29 kg
    Dimensions (LxWxH) 378 x 378 x 555

    Additional information

    Baujahr

    2007

    Manufacturer

    JUN-AIR

    Typ
