Description
Stack cutter Ideal 3915-95
from yr. KW 36-1999 condition like new
2 Knives
Mains connection: 230 V / 50 Hz / 1~
Motor power (rated input): 0.45 kW
Dimensions W 600 x D 695 mm x height 1070 mm
Weight: 106 kg with base cabinet
Color: pearl gray
Cutting length: 390 mm
Insert height: 40 mm
Residual cut: 35 mm
Insertion depth: 390 mm
-special cutting comfort due to electro-mechanical knife drive and optical cutting indicator (light line)
-Safety device on front and back table
-patented lever quick pressing
-side stop with dimension scale
-spindle guided back gauge
-Fine adjustment of dimensions via scale ring on the hand crank of the backgauge
-high quality knife made of Solingen knife steel
-knife depth adjustment from the outside
-simple knife change from the front
-stable all metal construction
-practical base cabinet with one shelf
SCS safety package (Safety Cutting System):
swiveling, electrically controlled safety cover in the working area
Safety cover on the back table
Main switch and safety lock with key
Two-hand cut release with repeat lock and simultaneity control
patented IDEAL safety drive
automatic knife return from any position
24 volt control
Disc brake for instant knife stop
Knife changing device with covered knife edge
Knife draft adjustment from the outside.
GS test, complies with the latest accident prevention regulations and
Safety regulations of the employers’ liability insurance association as well as the European CE standard.
