Description
electric WireO table punching machine RENZ DTP 340 M
with one punching tool pitch 3:1, round hole 4 mm
Powerful punching system for punching and perforating paper up to 340 mm working width.
With foot switch and vertical paper feed.
Punching capacity up to 35 sheets (depending on the tool).
Universally applicable due to quickly exchangeable tools.
Working width:340 mm (up to 680 mm due to the laterally open punching shaft, with two punching passes)
Punching thickness: max. 3.5 mm
interchangeable tools
quick format changeover due to punch that can be switched off
adjustable edge distance
Machine dimensions L x W x H:36 x 49 x 25 cm
Weight 31 kg
Connection:230V / 50Hz / 250W
Renz WBS manual closing machine for wire comb binding
The Renz WBS 340 with module holder can be connected to the DTP 340 M tabletop punching machine.
be hooked into an efficient and space-saving punching and binding system.
Performance features
with module holder as single binding device
can be used to close all wire diameters from ø 3/16″ – 1 1/2″ (5.5 – 38 mm) pitch-independent
Due to laterally open design also suitable for double closures (2 x 360 mm)
easy attachment to the DTP 340 M tabletop punching machine
Quality “Made in Germany
